This series of MMA reactors is a core piece of equipment specifically designed for the pre-processing steps in the production of methyl methacrylate (MMA) casting sheets. The equipment has an effective volume of 2 to 3 tons (approximately 2.5–3.5 m³), and the main body is constructed of high-quality S304 stainless steel. The Acrylic reactor is suitable for the precise proportioning and controlled prepolymerization reaction of MMA monomers with initiators, crosslinking agents, and other additives at approximately 90°C, generating a prepolymer slurry with moderate viscosity and stable performance, laying a crucial foundation for subsequent casting.
Core Applications
Achieve controlled prepolymerization of MMA monomers at a constant temperature of approximately 90°C, generating a prepolymer with good flowability and uniform molecular weight distribution.
Utilize a wide-range adjustable stirring system (0–130 rpm) to adapt to the mixing needs throughout the entire process, from low-viscosity monomers to medium-to-high-viscosity prepolymers, ensuring uniform reaction and sufficient heat dissipation, preventing localized overheating or explosive polymerization.
As a key pretreatment unit in the MMA sheet-making process chain, it directly affects the transparency, internal stress control, and mechanical properties of the final sheet.
Technical Parameters
|
Nominal Volume |
2000 L / 2500 L / 3000 L (corresponding to approximately 2–3 tons of MMA material) |
|
Main Body Material |
Waste PMMA Rotary Pyrolysis Reactor is constructed primarily from S304 stainless steel. It features a mirror-polished interior, offering excellent corrosion resistance, non-precipitating surfaces, and a high standard of cleanliness. |
|
Operating Temperature |
Room temperature ~ 100°C (typical polymerization temperature ≈ 90°C) |
|
Stirring Speed |
0 ~ 130 rpm, variable frequency stepless speed regulation, adaptable to viscosity changes at different reaction stages. |
|
Stirring Type |
Propeller type (or customized according to process), ensuring efficient mass transfer and gentle shear. |
|
Temperature Control System |
Diverse designs including outer half-pipe, outer jacket, and inner coil, enabling rapid heating and cooling |
|
Safety Features |
Explosion-proof variable frequency motor, double-end mechanical seal, nitrogen protection interface. |
Product Advantages
Precise Temperature and Speed Control: Stable polymerization environment at 90°C + flexible stirring at 0~130 rpm ensures stable and controllable prepolymerization reaction.
Safe and reliable: The MMA batch polymerization reactor ensures safe and continuous production through a fully enclosed nitrogen-sealed design, which suppresses the risk of MMA self-polymerization, and is protected by multiple safety interlocks.
High cleanliness and compatibility: S304 material meets the requirements of food/optical grade MMA processes, avoiding metal contamination.
Strong process adaptability: Seamlessly connects to downstream processes such as vacuum degassing and automatic molding, improving overall line efficiency.
Applicable Process Stages
This PMMA reactor is mainly used in the prepolymerization stage of MMA casting plate production. After prepolymerization at approximately 90°C and 0~130 rpm, the slurry is degassed and then injected into the mold to enter the gradient temperature curing stage.
