In the production process of methyl methacrylate (MMA) casting sheets, the prepolymer material, rapidly cooled to room temperature in a cooling kettle, needs to be briefly buffered before entering the vacuum degassing or molding process to balance the cycle time of the preceding and following processes and ensure a continuous and stable supply.
To this end, we have designed an MMA stirred tank with an effective volume of 6 cubic meters, specifically designed for the safe temporary storage of MMA prepolymer liquid after the reaction has been terminated. It maintains material homogeneity through low-speed, gentle stirring, preventing sedimentation or localized viscosity differences, and providing stable and homogeneous feed conditions for downstream processes.
Core Functions
- Receives room-temperature prepolymer liquid from the MMA cooling kettle;
- Maintains uniform material composition and viscosity through low-speed stirring, preventing stratification during settling;
- Serves as a flow-stabilizing intermediate tank connecting the cooling and molding/degassing processes, improving the automation and continuity of the entire production line.
Technical Parameters
|
Effective Volume |
The Acrylic stir reactor has an effective volume of 6m³, meeting the needs of single-batch or multi-reactor merging buffering. |
|
Temperature Operation |
QUANSHENG's professionally developed PMMA stirred reactor can operate at room temperature. |
|
Stirring System |
● Stirring Type: Propeller-type stirrer; ● Speed Range: 45 rpm, maintaining only micro-circulation of materials to avoid introducing air bubbles or shear-induced temperature rise. |
|
Main Body Material |
S304 stainless steel, with a mirror-polished inner surface, meeting the cleanliness requirements of optical-grade MMA materials. |
Design Features and Advantages
Simple Design, Low Maintenance
The acrylic agitated reactor features a straightforward construction without internal heat exchange components, minimizing potential leakage points and reducing energy consumption.
Low-Disturbance Agitation
Its ultra-low-speed stirring mechanism prevents air entrainment, ensuring highly efficient downstream vacuum degassing.
Inherently Safe Operation
The reactor is fully enclosed and nitrogen-purged, eliminating the risk of flammable vapor accumulation and ensuring intrinsic safety.
